In Style, select a DimensionStyle to override.The overriding settings can be applied as long as no other DimensionStyle is set as active. These changes do not modify the DimensionStyle settings. You can temporarily change settings of the active DimensionStyle. Click Copy to copy the differences, or click Close.The DimensionStyle settings that differ are listed in the dialog box. In the Find Differences in DimensionStyles dialog box, in Compare and To, select a DimensionStyle.In Style, select a DimensionStyle to activate.Ī displays beside the active DimensionStyle.In Style, select a DimensionStyle to modify.Under Dimension, set up the DimensionStyle.This specifies that the new DimensionStyle is valid for all Dimensions or for a specific type of dimensioning. This style serves as the base settings for the new DimensionStyle.
In Based on, select an existing DimensionStyle.In the Create new DimensionStyle dialog box:.In the Options dialog box, the Drafting Styles page opens and Dimension expands. Click Format > Dimension Style (or type DimensionStyle).You can define DimensionStyles to apply annotative scaling for Dimensions. Use the DimensionStyle command to create and modify DimensionStyles.ĭimensionStyles control the way Dimensions look.
